The quickest and simplest way to explain the difference between line and load wiring is that line wires bring power into a system from an external power source. Load wires are the outgoing lines that deliver the electricity out of the system and into the point of use, like an outlet or fixture. Both must be properly connected for a circuit to work.
Unless you’re a state licensed electrician, performing work on your electrical system is generally unsafe. High 5 is a home service company in Denver, CO, offering electrical services including electrical system repairs, installations, and maintenance to our service area, which includes Boulder, Columbine, Lafayette, Superior, Rollinsville, and other nearby communities. If you need any electrical work done, please give us a call. We offer safe, expert services at a reasonable price.
Definitions of Load and Line Wiring
“Load” and “line” wiring are names for different wires found within an electrical circuit.
Line wiring
Line wires are often called “hot” wires because they’re always electrified. They carry power from the source to a device. Handle these lines with extreme caution as they will cause injury or electrocution if mishandled or connected improperly. A line wire typically connects to a brass-colored screw terminal in the outlet, light switch, etc.
Load wiring
Load wires bring power from the source to a fixture or appliance, moving electricity down the chain and completing the circuit by carrying electricity away from a device. They’re typically only energized when the device is turned on or activated. Load wires are attached to silver screw terminals.
Differentiating Between Load and Line Wiring
Some of the ways to differentiate between load and line wiring are:
Check the color
When looking at load vs. line wire, you’ll notice they’re usually color-coded as a safety measure used for easy identification. The “hot” line wire is usually black, and the load wire is green or white. There is no guarantee that every electrician uses the same color coding system, though, so an abundance of caution is always smart.
Test the voltage
Using a voltage tester, voltage detector pen, or multimeter, you’ll be able to tell the line wire as it’ll remain live even when the switch or device is turned off. Load wires, on the other hand, will not register on the devices when the switch is off, unless improperly installed.
Understanding Load Wiring
Load wires are wires that carry electricity from a device or appliance back to the power source, to complete the electrical circuit. You may remember the “load” wire as the one that is “loaded” by the device in question. For example, your light switch “loads” the wire with electricity when it’s turned on.
Exploring Line Wiring
The line wiring in your home is known as “hot”, permanently coursing with electricity from the electrical box or power source, as long as the breaker isn’t tripped. For safety reasons, line wires are often connected to fuses or circuit breakers.
Applications and Scenarios for Load vs Line Wiring
Electricians must understand the difference between load and line wiring when installing, repairing, replacing, or troubleshooting issues. GFCI outlets are dangerous if the load and line wires are in the wrong spot, because they’re designed to shut power off if there’s a ground fault. Light switches and dimmers are less dangerous but won’t work properly if the wires aren’t connected right.
Common Mistakes and Misconceptions
When it comes to line and load wires, mistakes may lead to short circuits or electrocution. Do not work on electrical systems unless you’re properly trained to do so. The following are some common mistakes and misconceptions related to line vs. load wiring.
Mixing up the line and load wires in a circuit
This causes “backfeeding”, which will result in a malfunctioning circuit, as electricity is fed back into the electrical grid, causing electrical shock.
Thinking the load wire is only hot when the switch is activated
In reality, there are moments when load wires carry electricity, even when the device is switched off, especially if there’s a problem with the electrical circuit like improper wiring or a fault in the switch. Never assume touching an electrical wire is safe when the power’s on.
Connecting the load and the line wires
Connecting these two wires destroys the circuit, bypassing all appliances and devices, looping back to the power source, and increasing the risk of personal injury and fires. If you’re not trained in electrical work, call an electrician to install your appliances, lighting, outlets, or other electrical items.
Troubleshooting Load vs Line Wiring Issues
Electrical installation and repairs are always best left to the professionals. Call an expert rather than trying to troubleshoot any issues yourself. These are some common tasks an electrician will take.
Turn the power off
One of the first tasks when working with electricity is to turn the power off. This is a safety measure that should never be overlooked.
Do a visual inspection
Labels often specify line and load terminals, and in many cases the line wire will be a different color from the load wire. Sometimes the receptacle, like a GFCI outlet, will be labeled as well.
Your electrician may also check the wire locations and electrical panel for labels that associate circuits to wires to narrow down the source of the problem, looking for all cues that tell them which is which.
Use a multimeter
A multimeter is an instrument that measures electrical properties, including current, resistance, and voltage. The electrician will touch this device to the load and line wires, to determine which wire is which, and if there’s a short circuit.
